End coupling 10KVTp0-1 (1x70; 95; 120)
- installation type: indoor
- number of cores in the cable: 1
- cable core cross-section: 70; 95; 120 mm 2
- cable insulation: oil-impregnated paper insulation. It is possible to use a coupling on a cable with PVC insulation.
- with or without armor
- voltage: from 6 to 12 kV
- tips: NO
Installation of the grounding unit on the cable armor is carried out by soldering; for this purpose, the coupling kit includes solder fat and solder.
A solderless grounding kit is used to ground the metal shell. It consists of a grater, a constant pressure spring and a ground wire with a lug.
Operation of couplings is allowed at ambient temperatures from -50ºС to +50ºС, as well as at relative air humidity up to 98%
When using couplings on cables with impregnated paper insulation, a level difference of -25 m is allowed when installing the coupling at the lower end of the cable.
Meets the requirements of GOST 13781.0-86
It is recommended to carry out all installation work using special Thermofit tools.
